2022 IBETAMAC IBBETAMAC 220
No longer available
2022 IBETAMAC IBBETAMAC 220
€32,000 +IVA PREZZO DI LISTINO EUR 50.000
Albano Laziale, Italy
Description
Ibetamac 220 mini series cnc machining centers with latest generation Siemens 808 D series CNC also suitable for institutions and educational use in technical institutes 24 month CE guarantee
Specifications
| Manufacturer | IBETAMAC |
| Model | IBETAMAC 220 |
| Year | 2023 |
| Condition | New |
| X axis travel (mm) | 400 |
| Y axis travel (mm) | 220 |
| Z axis travel (mm) | 450 |
| Table Spindle Nose End Light (mm) | 100-550 |
| Work surface length (mm) | 800 |
| Worktop width (mm) | 260 |
| Maximum weight allowed on the worktop (Kg) | 200 |
| Size of T-rail grooves (mm) | 14x80x3 |
| T-rail center distance (mm) | 80 |
| Spindle cone connection | BT 30 |
| Spindle speed (Rpm) | 80-6000 |
| Spindle head maximum power (Kw) | 3.7 |
| Positioning accuracy (mm) | +/- 0.012/300 |
| Repeatability (mm) | +/- 0.01 |
| Axis power (Kw) | X-Y-Z 1.5 |
| Axis feed speed (mm/min) | X-Y-Z 8000 |
| Maximum cutting speed (mm/min) | 8000 |
| Machine weight (Kg) | 1050 |
| Overall dimensions (mm) | 1700x1500x2100 |
| Power Supply (KVA) | 400V 3 phase 15KVA |
| CNC | Siemens 808 D latest generation |
